Thông số kỹ thuật:
- Công nghệ in: truyền nhiệt trực tiếp hoặc gián tiếp
- Độ phân giải: 300 dpi (12 dots/mm)
- Tốc độ: 4 ips
- Bề rộng khổ in: 4.16”(105.7mm)
- Bộ nhớ: 32 MB SDRAM, 16MB Flash ROM (USB storage up to 32GB)
- CPU: 32 bit RISC microprocessor
- Kết nối: USB device, RS-232, Ethernet, USB host
- Sensor: Reflective sensor x 1 (movable) & Transmissive sensor x 1 (fixed, 6.27mm offset)
- Font: Internal character sets standard 5 alpha-numeric fonts from 0.049”H ~ 0.23” H (1.25mm ~ 6.0mm) Internal fonts are expandable up to 24×24 4 direction 0 ~ 270 rotation Soft fonts are downloadable Ability to print any Windows True Type font easily Support scalable font
- Mã vạch 1D: tất cả
- Mã vạch 2D: PPLA/PPLB/PPLZ: MaxiCode、PDF417、Data Matrix (ECC 200 only) 、QR code、Composite Codes、Aztec
- Media: Max. width: 4.65” (118mm). Min. width: 0.88” (22.4mm). Thickness: 0.0024”~0.0075” (0.06mm~0.19mm) 5”(127mm) OD on a 1”/1.5” (25.4/38 mm) ID core; Dealer Option external media stand 8” OD on 1”/3” ID Core
- Ribbon: Ribbon width: 1.6”~4.33”(40 mm~110mm), Ribbon length: Max. 300m. Core size ID 1”(25.4 mm) or 0.5”(12.7mm) Wax, Wax/Resin, Resin (Ribbon wound ink-side out or ink-side in: auto-detect)
- Kích thước: W 220.6mm x H 187.5mm x D 278.5mm
- Nguồn điện: Universal Switching Power supply. AC input voltage: 100~240V, 50~60Hz. DC Output: 24V, 3.75A
- Môi trường hoạt động: 41°F~104°F (5°C~40°C)
- Môi trường bảo quản: -4°F~140°F (-20°C~60°C)
- Độ ẩm: 0% ~ 90% non-condensing
- Phụ kiện gắn thêm: Guillotine-Full Cutter / Partial Cutter, Dispenser , External media stand, Bluetooth, WLAN
