Thông số kỹ thuật:
- Công nghệ in: truyền nhiệt trực tiếp hoặc gián tiếp
- Độ phân giải: 300dpi
- Tốc độ: 4ips
- Bề rộng khổ in: Max. 4.1”(104mm)
- Bộ nhớ: 8MB DRAM, 8MB Flash ROM
- CPU: 32 bit RISC microprocessor
- Kết nối: USB device, RS-232, Parallel
- Sensor: Reflective sensor x 1 (Movable) & Transmissive sensor x 1(Center fixed)
- Font: Internal character sets standard 5 alpha-numeric fonts from 0.049”H ~ 0.23” H (1.25mm ~ 6.0mm) Internal fonts are expandable up to 24×24 4 direction 0° ~ 270° rotation Soft fonts are downloadable
- Mã vạch 1D: tất cả mã 1D
- Mã vạch 2D: PPLA/PPLB: MaxiCode、PDF417、Data Matrix (ECC 200 only) 、QR code、Composite Codes
- Media: Max. width 4.3”(110mm) Min. width 1” (25.4 mm) Thickness 0.0025”~0.01” (0.0635mm ~0.254mm) Max. roll capacity (OD): 5″(127 mm) Core size 1”(2.54mm) Max. roll capacity (OD): 4.5″(114.3 mm) Core size 0.5”(12.7mm) Optional Max. roll capacity (OD): 4.7″(120 mm) Core size 1.5”(38.1mm) Optional
- Ribbon: Ribbon roll – OD: 2.6”(67mm) Ribbon Length: Max. 300m Core size – ID: 1”(2.54mm) Ribbon Width:1″~4.33″(25.4mm~110mm) Wax, Wax/Resin, Resin (Ribbon wound ink-side out or ink-side in: auto-detect)
- Kích thước: W 225mm x H 186mm x D 273mm
- Trọng lượng: 2,1kg
- Nguồn điện: Universal Switching Power Supply AC Input: 100V~240V, 1.8A, 50~60Hz, DC Output: 24V 2.4A
- Môi trường hoạt động: 40°F~100°F (4°C~38°C)
- Môi trường bảo quản: -4°F~122°F (-20°C~50°C)
- Độ ẩm: 0% ~ 90% non-condensing
- Phụ kiện đặt thêm: Guillotine-Full Cutter / Partial Cutter, Rotary Cutter, RTC card, External media stand
